High-Precision Copper Strips by Nitro Metals: Excellence in Every Dimension
At Nitro Metals, we are dedicated to producing copper strips that set the industry benchmark for quality, performance, and reliability. Our commitment to excellence is reflected in every copper strip we manufacture, ensuring they meet the precise needs of our diverse clientele. From electrical engineering to decorative applications, Nitro Metals's copper strips are engineered to provide superior functionality and aesthetic appeal. Leveraging advanced manufacturing technologies and a commitment to sustainability, we offer copper strips that are not only high in quality but also environmentally responsible.
Key Features
Explore the outstanding features of our Copper Srtip
-
Optimal Electrical Conductivity:
Our copper strips are designed for exceptional electrical conductivity, making them perfect for high-demand electrical applications where efficiency is paramount.
-
Exceptional Formability:
Thanks to their excellent malleability, our copper strips can be easily shaped, bent, and formed into complex designs without compromising their integrity, ideal for custom manufacturing needs.
-
Advanced Corrosion Resistance:
Treated surfaces and alloy compositions ensure that our copper strips withstand corrosive environments, prolonging their lifespan and maintaining their performance.
-
Pristine Surface Finish:
Each strip is processed for a smooth, clean finish, enhancing its appearance and functional qualities, suitable for both industrial and decorative uses.
-
Sustainability Focus:
Manufactured from recyclable copper, our strips contribute to eco-friendly production cycles and sustainability goals, emphasizing our commitment to protecting the environment.
Copper Strip Specifications:
| Parameter | Value |
|---|---|
| Material Thickness | 0.05mm to 3mm |
| Strip Width | Up to 400mm |
| Length Customization | Available in coil or specified lengths |
| Electrical Conductivity | ≥ 98% IACS (International Annealed Copper Standard) |
| Material Grade | Pure copper (C11000) and other alloys as per customer request |
| Temper Options | Soft (O), Half-Hard (H02), Full-Hard (H04) |
Copper Strip Mechanical Specifications:
| Mechanical Property | Specification |
|---|---|
| Tensile Strength | 200 - 400 MPa (depending on temper) |
| Elongation | 3% - 40% (based on temper and thickness) |
| Hardness | 45 - 120 HV (Vickers Hardness) |
| Density | 8.93 g/cm³ (standard for pure copper) |
Types of Copper Strip:
-
Bare Copper Strip:
Ideal for electrical and grounding applications, these strips offer unmatched purity and conductivity.
-
Tinned Copper Strip:
With a thin layer of tin plating, these strips are perfect for applications requiring enhanced solderability and corrosion resistance.
-
Braided Copper Strip:
Offering superior flexibility, these strips are composed of finely braided copper wires, ideal for flexible connections and grounding straps.
-
Laminated Copper Strip:
Constructed with multiple layers of copper for increased mechanical strength and conductivity, these strips are suited for high-current applications where durability is critical.
Applications & Uses of Copper Strip
- Electrical connectors and terminals
- Automotive components
- Transformer windings
- Circuit board tracks
- Building construction
- Decorative items
Service Result
Get personalized guidance from our knowledgeable team to make informed decisions about our products.
Tailor our products to your unique needs with assistance in adapting dimensions, materials, and finishes.
Enjoy ongoing assistance for troubleshooting, installation, and product maintenance, ensuring seamless operations.
Quality service for construction projects and Automative service.
